Product Feature
IR Remote control power switch on/off
Phone jamming device Using ultrahigh frequency boardband jamming technology.
Effective power (Channel power) high, and interference radius big
Valid subsection, only interference downlink, not cause interference to the base station.
Import component, slow starting circuit design and can avoid mechanical switch generated spark phenomenon, high level of integration and working stabilization
Perfect self-protective function, when the equipment overheating, output over power, VSWR ect fault warning, the jammer will auto turn-off which have fault module, to avoid the jammer damage.
Ethernet IP Remote Monitoring System available
RF module alarm type: Temperature alarm, Owe power alarm, Standing wave alarm.
Easy operation, plug in and play
Product Specificaiton
Effective shielding CDMA, GSM, SCDMA, DCS1800MHz, PCS1900MHz, PHS, GPS, 2.4GWIFI, 5.8G wifi, 3G WCDMA, 4G LTE,5G,VHF,UHF ect, wireless signal.
Working frequency bands (made by Frequency environment ):
Channel | Frequency | RF output Power |
Band 1 | CDMA | 10W |
Band 2 | DCS1800MHz | 10W |
Band 3 | PCS1900MHz, | 10W |
Band 5 | 3G WCDMA | 10W |
Band 6 | 4G LTE | 10W |
Band 7 | 2.4G WIFI | 10W |
Band 8 | 5.8 G WIFI | 10W |
Total RF output power: 80W
In-band Flatness: 2dB
Internal Modulation: Analog or DDS Module
Effective jamming range: 20-80m depending on the environment signal strength;
Power supply:110-220V DC 24V (Optional)
Continuous working hours: 247hours ongoing working.
Power Consumption: 90 W
Remote Control: Ethernet IP Remote Monitoring System
Remote Control Interface: RJ45
IP Level: IP53
Antenna type: High Gain Directional Panel Antennas or Omni Antennas
Antenna Gain: 12dBi
Built-in battery: No.
Operating Temp: -20ºC - plus 55ºC
Humidity: 30 percent -95 percent
Dimension: 400x 300x 115 mm (L x W x H)
Packing size: 530 x 370 x 240 mm (L x W x H)
Net Weight: 10.5kgs;
Accessoris: Power cable, antenna, RJ45 connector, wall-mounted expansion bolt.
Application:
Prisons, Recording Studios, Banks, Contract Tendering Rooms, Churches, Classrooms, Testing Facilities, Security Services, Military Units, Secret Services, News Conference Rooms, Libraries, Museums, Courts, Border Patrol and Drug Enforcement, Customs, etc.
Any sensitive locations where the wireless signals are not allowed.
